Hardware Specification
|
|
Fast Ethernet Ports
|
16
10/100Base-TX RJ-45 Auto-MDI / MDI-X ports
|
|
Gigabit ports
|
2
Gigabit SFP +2 Gigabit Uplink
|
|
Power over Ethernet ports
|
16-Port
with PoE injector function
|
|
Switch Processing Scheme
|
Store-and-Forward
|
|
Switch fabric
|
7.2Gbps
|
|
Flow Control
|
Back
pressure for half duplex, IEEE 802.3x Pause Frame for full duplex
|
|
Dimensions
|
440
x 350 x 45 mm (1U height)
|
|
Weight
|
5kg
|
|
Power Requirement
|
100-240V
AC, 50-60 Hz
|
|
Temperature
|
Operating:
0~50 ℃
|
|
Storage: -40~70 ℃
|
|
Humidity Operating
|
5%
to 90%, Storage: 5% to 90% (Non-condensing)
|
|
Warranty
|
1
year
|
|
Power over Ethernet
|
|
PoE Standard
|
IEEE
802.3af/at Power over Ethernet / PSE
|
|
PoE Power Supply Type
|
End-Span
|
|
PoE Power Output
|
Per
Port 48V DC, Max. 30 watts
|
|
Power Pin Assignment
|
1/2(+),
3/6(-)
|
|
Power dissipation
|
250
watts
|
|
Standards Conformance
|
|
Certifications
|
FCC
, CE, ROHS
|
|
Standards Compliance
|
IEEE
802.3 Ethernet
|
|
IEEE 802.3u Fast Ethernet
|
|
IEEE 802.3ab Gigabit Ethernet
|
|
IEEE 802.3z Gigabit Ethernet
|
|
IEEE 802.3x Full-duplex Flow control
|
|
IEEE 802.3af Power over Ethernet
|
|
IEEE 802.1Q VLAN
|
|
IEEE 802.1p QoS
|
